The HELIOS kiln controller has been created with an advanced technology with the intention of obtaining good reliability and great performances with a very low price, by removing all unnecessary parts for the correct run of drying process. This instrument is particularly suitable for any kind of control on small kilns or, generally, on all systems in which is necessary to keep a good standard of quality and to reduce costs: HELIOS is the instrument with the best price/performance ratio today available on the market. With a simple first program setup, which can be made by recalling a drying program from the memory (a standard one or a program previously saved by the user), the HELIOS controller is able to run the drying cycle in a fully automatic way. The HELIOS controller contains into a single sealed box (IP55) the control panel and the amplifier for signals detected by timber probes. For this reason it must be placed close to the chamber, operation made easier thanks to its wide working temperature range.

Technical specifications

• Temperature measurement: 0-99ºC
• Equilibrium moisture measurement (EMC): 6-30%     @25ºC
• Timber moisture measurement: 8-90% @25ºC



Inputs

• 4 timber probes
• 1 temp. probe (second probe optional )
• 1 equilibrium moisture probe (second probe optional)

Outputs

• 6 Relay outputs to control:
• Fans (manual or automatic control)
• Flaps (manual or automatic control)
• Sprayers (manual or automatic control)
• Heating (manual or automatic control)
• Reversal of fans rotationAlarm
• Probe Box for Easy/Helios

The HELIOS controller is supplied with the following parts:

• Panel with roof to be placed into the kiln, provided with    clamp for cellulose, temperature probe, 10m long high    insulation cables (Teflon©)
• 3 sets of 10 electrodes (L=15/25/40 mm) to be placed    on wood
• 50 cellulose plates
• 4 high insulation cables (Teflon®) for connection with    electrodes
• Instructions manual with quick reference table
• Accessories for assembly

  Options

• Double equilibrium moisture and temperature probe
• RS232 - RS485 Converter for network connection
• Control software for P.C. (Windows®95/98/NT/Vista/7/8)

SS Stainless Steel Pins (Plain)

Lenght 15 mm * - CODE:  C009

Lenght 25 mm * - CODE:  C010

Lenght 40 mm * - CODE:  C011

* Sold in packs of 20

SS Stainless Steel Pins (Threaded)

Lenght 15 mm * - CODE: C1484

Lenght 25 mm * - CODE: C1485

Lenght 40 mm * - CODE: C1486

* Sold in packs of 20

Probe Panel

- c/w 10 m Multicore   Teflon Cable to Helios   Controller

  CODE : C001

ACCESSORIES

Aluminum Probe Panel

- Probe box with EMC   sensor holder, 4 MC points

, Temperature sensor and   Cable Lugs.

  CODE : C002

Teflon MC Cable

-with 4 Banana Pliugs

- available in 6, 8, 10 mL

 6m L -  CODE : C003

 8m L -  CODE : C004

10m L - CODE : C005

Banana Plug

- High Temperature Rubber

  CODE : C006

- Stainless Steel Connector

  CODE : C001

 HELIOS TIMBER DRYER CONTROLLER
