  HYDROMETTE HT 65
 HYDROMETTE HT 65
The HT 65 is an electronic wood moisture meter based on the electric resistance measurement principle. It is designed for precise measurements of sawn timber (up to 180 mm thick), particle boards and veneers. The device is ideal for both single and series measurements before, during and after processing wood.
The Hydromette is especially applicable for saw mills, parquet manufacturing and woodworking industries.

     SPECIFICATIONS

Measuring Range - 4 to 60%

Resolution - 0.1% MC

4 Selectable Wood Groups to cover over 300 wood species

Can measure MC of Particle Boards

Selectable Temperature Calibration from -10 to +40oC

Power Supply - 9 Volt Battery
 HYDROMETTE HT 85

The HT 85 T is a triple measuring instrument for wood moisture, structural moisture and temperature. It is designed for precise measurements of sawn timber (up to 180 mm thick), particleboards, veneers and hardened building materials.

In order to monitor the kiln drying of timber, it can be combined with any disired number of MC, EMC and temperature in-kiln measuring points.

An Optional Temperature Sensor is available for measuring ambient and wood temperature.


      SPECIFICATIONS

Measuring Range - 4 to 100%

Resolution - 0.1% MC

4 Selectable Wood Groups to cover over 300 wood species

Can measure MC of Paticle Boards and Building Materials

Selectable Temperature Calibration from -10 to +90oC

Power Supply - 9 Volt Battery
Made in Germany
Electrode Holder
MK8 Measuring Cable
Teflon Insulated Pins
45 mm , 60 mm
Non Insulated Pins
23, 40, 60 mm
M18 Hammer  Electrode

  INTRODUCING TWO   COMPACT AND AND   ECONOMICAL METERS   FROM GANN GERMANY

  ACCESSORIES
